Smart Film



Make the film transparent or opaque with a simple flick of a switch.



Smart Film is an advanced product that can instantaneously switch from a transparent state to an opaque state through   application of electricity. Smart Film features two sheets of film that sandwich liquid crystals. Applying electricity to the film rearranges the crystal molecules, allowing light to pass through the film.

Magic Film is available in a wide range of dimensions and shapes.

Smart Film can be ordered in dimensions as large as 1000 mm / 1,200 mm / 1500mm  x 3,200 mm and can be used fore variety of applications.

The dispersion of the light that enters the film creates an opaque view. When the power is turned on, however, the liquid crystal molecules align themselves parallel to the direction of the applied electricity.



FEATURES



  •  Sizes: 1000 * 3200mm  ,   1200 * 3200mm or 1500 * 3200mm
  •   Custom sizes available
  •   Multi-Colour tints
  •   Thickness: Any type thicknes of glass
  •   Glass types: Curved, Shaped, Double Glazed, Triple Glazed, Drilled Holes
  •   Light transmittance – 80 ± 2% (On) / 60 ± 3% (Off)
  •   Haze Coefficient – On 5 ±1% (On) / 92 ± 2% (Off)
  •   Power  65 V – 110 V
  •   Frequency – 50/60Hz)
  •   Power – 5 watts per m2
  •   Switching – Less than 1 second

APPLICATIONS



  • Video / advertising screen
  •   Self adhesive film
  •   Exhibition / product launch
  •   POP / POS displays
  •   Store windows / retail displays
  •   Boardrooms / office partitions
  •   Museums / visitor attractions
  •   Conservatories / sun rooms

ACCESSORIES



  •   Interactive touch foil
  •   Wall switch
  •   Remote control
  •   Movement sensor
  •   Timer
  •   Door lock
  •   Audiopods / virtual sound sustem
